Granular packing machine

Features

1. Smart Sewing System with Touch Screen Control

2. Stable Operation with Precise Thread Management

3. Durable Design for Long-Term Performance

4. Intelligent Automation for Higher Efficiency

Technical Parameters

Packaging Range (kg): 5–50
Speed (bags/h): 300–900
Power Supply: 4N AC 380V / 50Hz / 1.1 kW
Air Consumption: 0.4–0.6 MPa
Machine Size(L×W×H): 3000 × 1050 × 2700 mm

Features

1. Suitable for Various Granular Materials

2. Accurate Weighing with Stable Performance

3. Reliable Components for Long-Term Operation

4. Intelligent Control with Flexible Automation Options

Technical Parameters

Packaging Range (kg): 5–50
Speed (bags/h): 300–400
Power Supply: 4N AC 380V / 50Hz / 1.5 kW
Air Consumption: 0.4–0.6 MPa / 1 m³/h
Machine Size(L×W×H): 2300 × 720 × 2465 mm

Features

1. Integrated Weighing, Sewing & Conveying

2. Fully Automatic & High Efficiency

3. Fast, Accurate & Stable Operation

4. Smart Control with Reliable Performance

Technical Parameters

Packaging Range (kg): 25–100
Speed (bags/h): 300–400
Power Supply: 4N AC 380V / 50Hz / 1kW
Air Consumption: 0.4–0.6 MPa / 1 m³/h
Machine Size(L×W×H): 3442 × 755 × 2800 mm

Features

1. Wide application for rice, grains and food granular packing.

2. Servo feeding with single-hopper design for fast, efficient filling.

3. Three-load-cell weighing with touchscreen control for high accuracy.

4. Stainless steel contact parts, fault alarm and RS232/RS485 data connection.

Technical Parameters

Packaging Range (kg): 5–50
Speed (bags/h):  500–1100
Power Supply: AC 220V, 50Hz / 1 kW
Air Consumption: 0.4–0.6 MPa / 6 m³/h
Machine Size(L×W×H): 2550 × 1160 × 2960mm

Features

1. Designed for accurate and stable 25kg flour packing.

2. Integrated weighing, conveying & automatic bag sewing system.

3. Hygienic SS304 contact parts with durable industrial structure.

4. High precision performance with easy operation and maintenance

Technical Parameters

Packaging Range (kg): 5–25
Speed (bags/h): 160-200
Power Supply: 3P4W AC 380V / 50Hz
Air Consumption: 0.5MPA/2m³/h
Machine Size(L×W×H):2149×1145×2760mm

Features

1. High-Precision Belt Weighing with Stable Performance

2. Suitable for Grain, Rice, Feed & Bulk Materials

3. Automatic Feeding, Weighing, Conveying & Sewing

4. Reliable Industrial Design with Easy Maintenance

Technical Parameters

Packaging Range (kg): 25–50
Speed (bags/h): 200
Power Supply: 3P4W AC 380V / 50Hz
Air Consumption: 5 m³/h
Machine Size(L×W×H): 2860 × 1400 × 3574 mm
